Home > Products > Raytek® Compact MI3- RAYMI310LTSCB3

Raytek® Compact MI3- RAYMI310LTSCB3

Login to see prices


Raytek RAYMI310LTSCB3 Infrared Temperature Sensor with 3m Cable, 22:1 Optics, 0 to 1000°C (32 to 1832°F) is a rugged, IP65-rated miniature sensing head that can be placed in harsh environments inaccessible to conventional sensors. The MI3 is not a stand-alone sensor and must be purchased in conjunction with MI3MCOMM communication box to function.

Key Commercial Data

Measurement Specifications
Temperature Range 0 to 1000°C (32 to 1832°F)
Accuracy ± (1% of reading or 1°C)
Spectral Response 8 – 14 μm
Repeatability (digital and voltage) ± 0.5% of reading or ± 5ºC, whichever is greater
Repeatability (t/c) ± 0.5% of reading or ±1ºC ± 2ºC, whichever is greater
Temperature Coefficient ± 0.05 K / K or ± 0.05% / K of reading
Response Time (95%) 130 ms
Optical Resolution 22:1
Applications Printing, coating, laminating, drying/curing, paper, food, textiles, carpet, sheet plastics, asphalt, pharmaceuticals


Spec Sheet

For more information like lead time, please contact : sales@dmarktech.com or call +65 67673232


**No Cancellation of Purchase Order Upon Acknowledgement**

** Delivery surcharge of $30 will be applicable if order is below $250 (BEFORE GST)**

** Warranty of 12 months starting from delivery date will be applicable only to manufacturer defects which will be repaired/replaced**
