Raytek® Compact CM- RAYCMLTK3M

Login to see prices

Overview

Raytek RAYCMLTK3M Infrared Temperature Sensor with RS232, Type K Output, 3m Cable, 18Mx1 Thread is a powerful, compact, integrated infrared sensor designed for continuous temperature monitoring that can easily replace traditional contact probes with a J-type or K-type thermocouple output, or with a user scaleable 0-5V output, if your application is susceptible to noise.

Key Commercial Data

Measurement Specifications
Temperature Range -20ºC to 500ºC (-4ºF to 932ºF)
Accuracy (mV) ± 1.5% of reading or ± 2ºC, whichever is greater
Accuracy (t/c) ± 1.5% of reading ± 2ºC or ± 4ºC,
whichever is greater
Spectral Response 8 to 14 microns
Repeatability (digital and voltage) ± 0.5% of reading or ± 2ºC, whichever is greater
Repeatability (t/c) ± 0.5% of reading or ±1ºC ± 2ºC, whichever is greater
Temperature Resolution 0.1°C
Response Time (95%) 150 mSec
Optical Resolution 13:1
Applications Printing, coating, laminating, drying/curing, paper, food, textiles, carpet, sheet plastics, asphalt, pharmaceuticals



Spec Sheet

For more information like lead time, please contact : sales@dmarktech.com or call +65 67673232



**No Cancellation of Purchase Order Upon Acknowledgement**

** Delivery surcharge of $30 will be applicable if order is below $250 (BEFORE GST)**

** Warranty of 12 months starting from delivery date will be applicable only to manufacturer defects which will be repaired/replaced**
